HackTheBox - APKey Walkthrough

The Android app had several Java classes—each holding small fragments of what eventually formed two critical pieces of data:

1. The AES Decryption Key: Built by concatenating individual characters selected from various string arrays.
2. The Encrypted Flag: Constructed by piecing together substrings from multiple arrays into one long Base64‑encoded ciphertext.

MainActivity

<?xml version="1.0" encoding="utf-8"?>
<manifest xmlns:android="<http://schemas.android.com/apk/res/android>"
    android:versionCode="1"
    android:versionName="1.0"
    android:compileSdkVersion="30"
    android:compileSdkVersionCodename="11"
    package="com.example.apkey"
    platformBuildVersionCode="30"
    platformBuildVersionName="11">
    <uses-sdk
        android:minSdkVersion="16"
        android:targetSdkVersion="30"/>
    <application
        android:theme="@style/Theme.APKey"
        android:label="@string/app_name"
        android:icon="@mipmap/ic_launcher"
        android:allowBackup="true"
        android:supportsRtl="true"
        android:roundIcon="@mipmap/ic_launcher_round"
        android:appComponentFactory="androidx.core.app.CoreComponentFactory">
        <activity android:name="com.example.apkey.MainActivity"> ⚠️
            <intent-filter>
                <action android:name="android.intent.action.MAIN"/>
                <category android:name="android.intent.category.LAUNCHER"/>
            </intent-filter>
        </activity>
    </application>
</manifest>

After taking a look at the AndroidManifest.xml, you’ll spot the MainActivity which we can navigate to for the core functionality.

Functionality for Main Activity

• Handling User Input: An inner class implementing View.OnClickListener is set on the button. When the button is clicked, the following steps occur:
  1. Username Verification: The code checks if the username equals "admin".
  2. Error Handling: If the credentials don’t match, the user sees a "Wrong Credentials!" message.

Triggering Decryption: If both the username and password match the expected values, the app calls:

b.a(g.a())

This call first assembles a Base64‑encoded ciphertext using class g and then decrypts it using class b. The decrypted message (which turns out to be the flag) is then shown to the user via a Toast (a popup feedback message).

Password Verification via MD5: The entered password is hashed using MD5. Each byte of the hash is converted to a hexadecimal string, and the final hash is compared to a hardcoded value:

if (str.equals("a2a3d412e92d896134d9c9126d756f"))

Unpacking the Obfuscation Layers

Once you pass the authentication in MainActivity, the app calls the decryption function. Let’s explore how the decryption mechanism is structured across various classes.

Fragmented String Storage

package c.b.a;

import android.util.Base64;
import javax.crypto.Cipher;
import javax.crypto.spec.SecretKeySpec;

/* loaded from: classes.dex */
public class b {
    public static String a(String str) {
        SecretKeySpec secretKeySpec = new SecretKeySpec((String.valueOf(h.a().charAt(0)) + String.valueOf(a.a().charAt(8)) + String.valueOf(e.a().charAt(5)) + String.valueOf(i.a().charAt(4)) + String.valueOf(h.a().charAt(1)).toLowerCase() + String.valueOf(h.a().charAt(4)) + String.valueOf(h.a().charAt(3)).toLowerCase() + String.valueOf(h.a().charAt(3)) + String.valueOf(h.a().charAt(0)) + String.valueOf(a.a().charAt(8)).toLowerCase() + String.valueOf(a.a().charAt(8)).toLowerCase() + String.valueOf(i.a().charAt(0)) + String.valueOf(c.a().charAt(3)).toLowerCase() + String.valueOf(f.a().charAt(3)) + String.valueOf(f.a().charAt(0)) + String.valueOf(c.a().charAt(0))).getBytes(), g.b());
        Cipher cipher = Cipher.getInstance(g.b());
        cipher.init(2, secretKeySpec);
        return new String(cipher.doFinal(Base64.decode(str, 0)), "utf-8");
    }
}

The decryption key and the ciphertext aren’t stored in one place. Instead, multiple classes—such as a, c, d, e, f, h, and i—each hold fragments of data. Each class has a method a() that returns a string extracted from an array. For instance:

public class e {
    public static String a() {
        ArrayList arrayList = new ArrayList();
        arrayList.add("TG7ygj");
        arrayList.add("U8uu8i");
        arrayList.add("gGtT56");
        arrayList.add("84hYDG");
        arrayList.add("ejhHy6");
        arrayList.add("7ytr4E");
        arrayList.add("j5jU87");
        arrayList.add("HyeaX9"); // Key piece
        arrayList.add("jd9Idu");
        arrayList.add("kd546G");
        return (String) arrayList.get(7);
    }
}

//e.a(5) returns the 5th character from the 7th item in the array list.

This method of scattering the data makes it challenging to immediately see the whole picture.

Assembling the AES Key in Class b

Class b is responsible for decrypting the ciphertext. It constructs the decryption key by concatenating specific characters from the outputs of the fragmented string methods. For example:

• h.a().charAt(0)
• a.a().charAt(8)
• e.a().charAt(5)
• i.a().charAt(4)
• Additional characters extracted from other classes with some converted to lowercase

When you follow the extraction sequence provided in class b, the resulting 16‑byte key is:

kV9qhuzZkvvrgW6F

Constructing the Encrypted Data in Class g

package c.b.a;

import java.util.ArrayList;

/* loaded from: classes.dex */
public class g {
    public static String a() {
        StringBuilder sb = new StringBuilder();
        ArrayList arrayList = new ArrayList();
        arrayList.add("722gFc");
        arrayList.add("n778Hk");
        arrayList.add("jvC5bH");
        arrayList.add("lSu6G6");
        arrayList.add("HG36Hj");
        arrayList.add("97y43E");
        arrayList.add("kjHf5d");
        arrayList.add("85tR5d");
        arrayList.add("1UlBm2");
        arrayList.add("kI94fD");
        sb.append((String) arrayList.get(8));
        sb.append(h.a());
        sb.append(i.a());
        sb.append(f.a());
        sb.append(e.a());
        ArrayList arrayList2 = new ArrayList();
        arrayList2.add("ue7888");
        arrayList2.add("6HxWkw");
        arrayList2.add("gGhy77");
        arrayList2.add("837gtG");
        arrayList2.add("HyTg67");
        arrayList2.add("GHR673");
        arrayList2.add("ftr56r");
        arrayList2.add("kikoi9");
        arrayList2.add("kdoO0o");
        arrayList2.add("2DabnR");
        sb.append((String) arrayList2.get(9));
        sb.append(c.a());
        ArrayList arrayList3 = new ArrayList();
        arrayList3.add("jH67k8");
        arrayList3.add("8Huk89");
        arrayList3.add("fr5GtE");
        arrayList3.add("Hg5f6Y");
        arrayList3.add("o0J8G5");
        arrayList3.add("Wod2bk");
        arrayList3.add("Yuu7Y5");
        arrayList3.add("kI9ko0");
        arrayList3.add("dS4Er5");
        arrayList3.add("h93Fr5");
        sb.append((String) arrayList3.get(5));
        sb.append(d.a());
        sb.append(a.a());
        return sb.toString();
    }

    public static String b() {
        return String.valueOf(d.a().charAt(1)) + String.valueOf(i.a().charAt(2)) + String.valueOf(i.a().charAt(1));
    }
}

The ciphertext is pieced together in class g:

• It begins with a fragment from one array (for example, the element at index 8: "1UlBm2").
• Then it appends results from h.a(), i.a(), f.a(), and e.a().
• More segments from additional arrays and calls to c.a(), d.a(), and a.a() complete the ciphertext.

The final concatenated Base64‑encoded string is:

1UlBm2kHtZuVrSE6qY6HxWkwHyeaX92DabnRFlEGyLWod2bkwAxcoc85S94kFpV1

This string is what gets decrypted once the authentication in MainActivity passes.

The Decryption Process

Inside class b, the following steps occur:

1. Key Setup: The 16‑byte key "kV9qhuzZkvvrgW6F" is used to create a SecretKeySpec.

Decoding and Decryption: The Base64‑encoded string from g.a() is decoded into bytes. The cipher then decrypts these bytes with the key, removing the padding to reveal the plaintext. If successful, the plaintext is the flag:

HTB{REDACTED}

Cipher Configuration: The cipher is initialized with:

Cipher.getInstance("AES")

This typically means AES in ECB mode with PKCS5Padding in Java.

Bringing It All Together with a Python Script

For verification—and to illustrate the process outside of the Android environment—we can mimic the decryption with a Python script using PyCryptodome. Here’s the complete script:

#!/usr/bin/env python3
from Crypto.Cipher import AES
import base64

def unpad(data):
    """
    Remove PKCS#7 (or PKCS#5) padding.
    """
    pad_len = data[-1]
    return data[:-pad_len]

def decrypt_flag(ciphertext_base64, key):
    # Create an AES cipher in ECB mode.
    cipher = AES.new(key, AES.MODE_ECB)
    # Decode the Base64 string to bytes.
    ciphertext = base64.b64decode(ciphertext_base64)
    # Decrypt and remove padding.
    decrypted = cipher.decrypt(ciphertext)
    return unpad(decrypted)

if __name__ == '__main__':
    # The Base64 string generated by g.a()
    ciphertext_base64 = "1UlBm2kHtZuVrSE6qY6HxWkwHyeaX92DabnRFlEGyLWod2bkwAxcoc85S94kFpV1"

    # The decryption key constructed in b.a()
    key = b'kV9qhuzZkvvrgW6F'

    try:
        decrypted_flag = decrypt_flag(ciphertext_base64, key)
        print("Decrypted flag:", decrypted_flag.decode('utf-8'))
    except Exception as e:
        print("Decryption failed:", e)

Running this script reproduces the decryption process from the Java code and prints out the flag:

HTB{REDACTED}
